DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7" OS05A10 Sensor Low Illumination for Thermal Camera

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7" OS05A10 Sensor Low Illumination for Thermal Camera

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera

Product Typ：DGZX-AS-AA018AA50M2-50×50

Active pixels：5MP 2688×1944

Sensor：OS05A10(1/2.7″)CMOS

View Angel/EFL：Lens optional

Format：12-/10-bit RAW RGB

Frame rate：2688×1944:60fps 2688×1520:60 fps

Features & application：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one

Interface：MIPI(Customizable USB/LVDS camera module )

Size：L*W:50*50mm(PCBA)

카테고리: 미피 카메라 모듈 태그: Low Illumination, HD, 60프레임, 5MP, 미피(MIPI)

문의하기 빠른 문의

설명
추가 정보

설명

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图1

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图2

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图3

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图4

DGZX 5MP Mipi Camera Module 1520P 60fps 1/2.7″ OS05A10 Sensor Low Illumination for Thermal Camera插图5

추가 정보

해결	5MP/2K

HD 5MP HDR MIPI CAMERA MODULE

Support for frame sync | 5MP 60fps | Wide angle lens option

Utral HD 5MP

2.5KP(2688×1944)60fps video output,support for frame sync

HDR Function

No fear of strong light, weak light, backlight

OS05A10 Sensor

HD image, high sensitivity, low power consumption

5°-240° Optional lens angle

Undistorted, panoramic lens can be selected arbitrarilyto meet all your needs

Widely used

Suitable for products in various industries

● Face recognition ● Mobile payment ● Video door phone ● Supervisingequipment ● Video conference ● Action camera ● Robot Vision ● Drone ● Big screen all-in-one
